Parallel Jaw Grip 2-1/2-Inch Length
- Free Shipping - U.S. Only
- In stock, ready to ship
- Backordered, shipping soon
Lightweight, compact grips pull an exceptionally wide range of cable sizes and types. Designed with a round inside-jaw contour for maximum contact to minimize conductor damage. Lower jaw is serrated to firmly grip insulated cables and conductors. Design includes a latch that prevents the grip from falling in case of jaw disengagement from the cable.
Features
- Lightweight, compact grips pull an exceptionally wide range of cable sizes and types
- Designed with a round inside-jaw contour for maximum contact to minimize conductor damage and lower serrated jaw to firmly grip insulated cables and conductors
- Design includes a latch that prevents the grip from falling in case of jaw disengagement from the cable
- Large-diameter eye accommodates large hooks on hoists, winches and tackle blocks
- Made in USA
Specifications
| Application | Cable Pulling |
| Jaw Type | Round |
| Jaw Length | 2.5" (6.4 cm) |
| Weight | 2.6 lb (1.2 kg) |
| Maximum Safe Load | 4500 lb (2041 kg) |
| Cable Type | Messenger, EHS, Coated |
| Type | Parallel Jaw Grip |
| Cable Diameter | 0.157" to 0.875" (3.98 to 22.22 mm) |
| Special Features | Spring |
| Material | Steel |
| Hot Latch | N |
| Spring | Y |
| Locking Handle | N |
| Style_Name | Safe Load 4500 lb |
| Configuration | Spring |
| Size_Name | 0.157" to 0.875" Cable Diameter |
| Swing Latch | N |
| Teeth Type | Coarse |
Warnings
- Before each use, clean jaw area and inspect grip for proper operation to avoid slippage.
- When used on/near energized lines, ground, insulate, or isolate grip before pulling.
- Do not exceed rated capacity.
- Do not exceed rated capacity.
- Grips are to be used for temporary installation, not for permanent anchorage.
