Versatile, one-handed grip holds a wide range of cable sizes pulling No. 6 Copper to No. 477 ACSR. 20-Percent lighter than the Klein's Cat. No. KT4500 grip with easy, one-handed actuation. Design includes a latch to help maintain cable position in grip jaws. Made in the USA, this grip has a maximum safe load of 5000-Pound.
Features
Wide Range Distribution Grip pulls No. 6 Copper to No. 477 ACSR 0.162 to 0.883-Inch (4.11 to 22.42 mm) cable
20-Percent lighter than the Cat. No. KT4500 grip
One-handed design makes for easier actuation
Made in the USA
Spring closes grip on cable to hold the initial position
Includes a latch to help maintain cable position in the grip jaw
Large opening in the handle accommodates a wide variety of hooks on hoists, winches and tackle blocks
Max Safe Load of 5000-Pound (2268 kg)
Patent pending design
Specifications
Standard
—
Weight
3.2 lb (1.5 kg)
Overall Length
10.25" (26 cm)
Locking Handle
Y
Cable Type
Bare Copper, Aluminum, ACSR
Hot Latch
Y
Material
Steel
Spring
Y
Jaw Type
Round
Overall Height
8" (20.3 cm)
Swing Latch
N
Application
Wire Pulling
Overall Width
1.75" (4.4 cm)
Jaw Length
3.31" (8.4 cm)
Special Features
Hot Latch
Maximum Safe Load
5000 lb (2268 kg)
Cable Diameter
0.162 to 0.883" (4.11 to 22.42 mm)
Type
Parallel Jaw Grip
Teeth Type
Fine
Warnings
Grips are to be used for temporary installation, not for permanent anchorage.
When used on/or near energized lines, ground, insulate, or isolate grip before pulling.
Do not exceed rated capacity.
Do not exceed rated capacity.
Before each use, clean jaw area and inspect grip for proper operation to avoid slippage.
